Operator 24 V for sliding gates up to 1500 kg in weight. Leaf speed 9 m/min. Magnetic limit switches: this type of limit switch ensures safe and precise installations in any ambient condition. Control unit with programming display: the Merak control unit with programming display with pre-programmed scenarios helps the installer in the programming phase; the control unit is arranged in an oblique way, to facilitate reading and making the settings. Front screws: this arrangement of the casing screws offers ease and convenience during installation and maintenance, even when there is limited space. Release lever with personalized key: the release lever simplifies motor release and the personalized key ensures its uniqueness, for better safety
Features
- Power Supply: 24V
- Max Gate Weight: 1650 lbs.
- Operator Control Unit: MERAK
- Gate Opening Speed: 39 ft/min.
- Impact Reaction: d-track
- Frequency of Use: Intensive
| Item | Gate Operator |
| Control Panel | MERAK |
| Max Leaf Weight | 3300 Lbs. |
| Leaf Speed | 7.8 ips (12 m/min) |
| Power Supply | 120V single-phase |
| Power Input | 400 W |
| Pinion Module | 4 |
| Slowdown | Yes |
| Locking | Mechanical |
| Release | Lever-Operated With Personal Key |
| Frequency Of Use | Intensive |
| Environmental Conditions | -4°F - 131°F |
| Protection Rating | IP44 |
| Operator Weight | 15.5 Lbs |
| Impact Reaction | D-Track |
| Dimensions | 13'' x 12'' x 10'' |
| Weight | 18 lbs |
Operator 24 V for sliding gates up to 1500 kg in weight. Leaf speed 9 m/min. Magnetic limit switches: this type of limit switch ensures safe and precise installations in any ambient condition. Control unit with programming display: the Merak control unit with programming display with pre-programmed scenarios helps the installer in the programming phase; the control unit is arranged in an oblique way, to facilitate reading and making the settings. Front screws: this arrangement of the casing screws offers ease and convenience during installation and maintenance, even when there is limited space. Release lever with personalized key: the release lever simplifies motor release and the personalized key ensures its uniqueness, for better safety
Features
- Power Supply: 24V
- Max Gate Weight: 1650 lbs.
- Operator Control Unit: MERAK
- Gate Opening Speed: 39 ft/min.
- Impact Reaction: d-track
- Frequency of Use: Intensive
| Item | Gate Operator |
| Control Panel | MERAK |
| Max Leaf Weight | 3300 Lbs. |
| Leaf Speed | 7.8 ips (12 m/min) |
| Power Supply | 120V single-phase |
| Power Input | 400 W |
| Pinion Module | 4 |
| Slowdown | Yes |
| Locking | Mechanical |
| Release | Lever-Operated With Personal Key |
| Frequency Of Use | Intensive |
| Environmental Conditions | -4°F - 131°F |
| Protection Rating | IP44 |
| Operator Weight | 15.5 Lbs |
| Impact Reaction | D-Track |
| Dimensions | 13'' x 12'' x 10'' |
| Weight | 18 lbs |
